Recording
- Connect the ‘CAN1 High’ and ‘CAN1 Low’ ports of the expansion connector to the appropriate wires/cable.
- Connect the LabSat 3 antenna (RLACS198) to the ‘RF IN’ port.
- Power up the LabSat 3 and navigate to the ‘CAN’ section of the menu. Set the CAN recording type to ‘Log file’ and set the baud rate for both CAN channels.
- Fit the expansion connector to the LabSat.
- Pressing the ‘REC’ button on the front of the LabSat will begin the recording. The LabSat will record all CAN data available on the connected Bus.

Replaying
- Connect the ‘CAN1 High’ and ‘CAN1 Low’ ports of the expansion connector to the appropriate wires/cable.
- Connect the device under test to the LabSat 3 ‘RF OUT’ port.
- Power up the LabSat 3 and select the previously recorded CAN scenario.
- Fit the expansion connector to the LabSat.
- Pressing the ‘Play’ button on the front of the LabSat will begin the replay. The LabSat will replay all CAN data originally recorded.
